Diamond GD50

Diamond GD50

Diamond GD50

Simple. Accurate. Reliable.

The innovative IST Technology and easy-to-use design will cover all the basics. Accuracy and ease of use are all you need to get started.

Features and Benefits

GDH-FAD Enzyme

Diamond Series Test Strips (GDH-FAD)

With the new IST Technology the Diamond Series strips ensure high accuracy and precision at wide hematocrit ranges.

Quick Results

No coding

Removes the needs for using a code card, improving the users’ experience.

Tiny Blood Sample

Tiny blood sample

Only 0.5μL of blood sample required.

Strip Ejection

Strip Ejection Design

The hygienic strip ejection design allows users to remove test strips without contact, reducing the possibility of cross infection.

Ketone Warning

Ketone warning

Be aware of abnormal ketone levels at glance.

  • Bluetooth

    Turn on Bluetooth
    on the product


Keep track of your results and manage your patterns and trends over time.

Product Specifications

Test Strip

Diamond Series Test Strips

Enzyme / Measurement technology



No coding

Sample volume


Measuring time

5 seconds

AST (Alternative Site Testing)

Palm, forearm and upper arm

Blood sample source

Capillary and venous whole blood

HCT range

20 – 60%

Day average

7, 14, 21, 28, 60, 90 days

Daily alarm


AC/PC recording


Measurement range

20 ~ 600 mg/dL

LCD backlight


Universal Tone


Meter dimensions (L x W x H)

104.4 x 58 x 23 mm

Weight (without battery)

71.2 g

Power supply

AAA x 1

Memory capacity


Operating temperature

10°C ~ 40°C (50°F to 104°F), below 85% R.H. (non-condensing)


RS-232 / BLE Dongle
